Product Overview
This product is an air-cooled comfort air conditioning chiller specifically designed to provide chilled water for office areas, control rooms, canteens, exhibition halls, inspection centers, and other occupied spaces within industrial buildings. Through terminal units such as fan coil units and air handling units, it delivers summer cooling to create a comfortable working environment for personnel.
As a comfort air conditioning cooling source for industrial buildings, this product features air-cooled heat rejection with an integral air-cooled condenser - eliminating the need for cooling towers and water treatment systems for a simple, flexible installation. The operating ambient temperature range is -5℃ to +43℃, with a chilled water temperature range of 7~12℃ (standard comfort air conditioning conditions). Compressor types can be selected from scroll or screw based on cooling capacity requirements to suit industrial buildings of varying scales.
Key Features
Energy Efficient
Equipped with high-efficiency compressors and heat exchangers, featuring electronic expansion valves for precise cooling capacity control. With comfort air conditioning systems typically operating under part-load conditions for extended periods, the system is optimized for superior part-load efficiency - significantly reducing annual operating electricity costs. Optional EC fans further reduce terminal equipment energy consumption.
Reliable & Durable
Built with rigorously tested, high-quality components, engineered for 24/7 continuous operation. Equipped with comprehensive automatic alarm and diagnostic functions, providing real-time alerts for abnormal operating parameters to prevent failures. Intelligent power monitoring is provided as standard, delivering real-time alerts for phase loss, phase reversal, overvoltage, undervoltage, and other power anomalies.
Quiet & Comfortable
Designed with low-noise operation to meet the acoustic sensitivity of occupied spaces. Both compressors and fans are selected from low-noise models, with overall unit noise levels significantly lower than industrial process cooling equipment - ensuring comfort in offices, meeting rooms, and rest areas.
Smart Control
Equipped with multiple sizes of true-color touchscreen displays, multi-level password access control, and self-diagnostic system functions. Comprehensive monitoring and display of key parameters including power supply voltage, frequency, cooling capacity, chilled water supply/return temperatures and differential, and ambient temperature. Supports RS485 / Modbus communication protocols, flexibly configurable based on project requirements for centralized monitoring and remote management through factory or campus central management systems. Supports auto-restart after power failure, scheduled on/off, and local historical data storage with logging and querying of operating parameters and event logs - storage capacity flexibly configurable based on project requirements.
Flexible Deployment
Features a compact integrated design with a small footprint, suitable for outdoor or rooftop installation. Factory pre-assembled and pre-commissioned, requiring only power connection and water piping on-site for immediate operation - significantly reducing installation time.
Applications
- Office Areas in Industrial Plants (Offices, Meeting Rooms, Exhibition Halls, etc.)
- Factory Control Rooms and Duty Rooms
- Employee Canteens, Dormitories, and Activity Centers in Industrial Parks
- Inspection Centers and Laboratories in Industrial Buildings
-
Various Occupied Spaces in Industrial Buildings Requiring Comfort Air Conditioning
Technical Advantages
Air-Cooled Heat Rejection, No Cooling Tower Required
Integral air-cooled condenser eliminates cooling towers, pumps, and water treatment systems - simple system, easy installation
Comfort-Focused Design
Low-noise operation meets acoustic comfort requirements for occupied spaces in industrial buildings
Smart Control & Communication
Standard touchscreen display and RS485 communication interface, Modbus protocol support for seamless integration with factory management systems
Integrated Design, Easy Installation
Factory-assembled unit, ready for operation upon on-site connection of power and piping - rapid deployment
System Selection Reference
|
Selection Dimension |
Available Options |
Application Scenario |
|
Compressor Type |
Scroll / Screw |
Selected based on cooling capacity scale |
|
Chilled Water Temperature |
7~12℃ (Standard Comfort Conditions) |
Suitable for comfort air conditioning in occupied spaces |
|
Terminal Type |
Fan Coil Unit (FCU) / Air Handling Unit (AHU) |
Selected based on building space and interior requirements |
Air cooled chiller delivers efficient, comfortable, and reliable comfort air conditioning cooling solutions for occupied spaces in industrial buildings through air-cooled simplicity, low-noise operation, and flexible configuration options.
Note: The above system description serves as a reference for standard functionality and architecture, intended to demonstrate core capabilities. Actual project solutions require customized design based on building scale, usage conditions, and client specifications. Final configurations are subject to project-specific selection. For inquiries, please contact us through any of the channels listed on our "Contact Us" page, and we will provide preliminary solution recommendations based on your specific project needs.
